Strain Cable Sensor
Long gauge strain sensor with 30cm to 10mtr measuring base (gauge length). SC-01 is measuring strain between its anchoring brackets and is therefore immune to local defects or inhomogeneity. Integrated temperature compensation. SC-01 can be connected in series configuration.
| Manufacturer | Sylex |
|---|---|
| Product code | SC-01 |
| SKU | 53839000006215284 |
| Description | Optical Sensor, FBG, strain cable |
Features
- Measurement of large structures with fewer sensors. One-body design for both strain and temperature measurement.
- Can be both concrete embedded and surface mounted.
- Adjustable pre-strain during installation.
- Customisable gauge length.
Applications
- Strain profile in concrete or metal structures (ceiling pillars, roofs, walls)
- Crack monitoring
- Deformations
- Borehole deformation (embedded or grouted)
Downloads
Please feel free to share or download any of the provided data sheets.
Strain Cable Sensor data sheetPDF · 364 KB · SylexDownloadAlso in Fibre Strain Sensors
View the Fibre Strain Sensors range
Get a quote for the Strain Cable Sensor
The product is filled in for you. Tell us the quantity and the application and we will come back with options and pricing.
